SMD Stage LED Display Structure Accurate Tolerance Fast Cabinet Splicing

Name: SMD Stage LED Display Structure Accurate Tolerance Fast Cabinet Splicing
Brand: PASSION
Price: 1 USD

China SMD Stage LED Display Structure Accurate Tolerance Fast Cabinet Splicing wholesale

Brand Name : PASSION

Model Number : P3.91mm

Certification : CE ROHS

Place of Origin : SHENZHEN , CHINA

MOQ : 8 panels

Price : Negotiation

Payment Terms : T/T, Western Union, MoneyGram, L/C

Supply Ability : 5000 square meter per month

Delivery Time : 15 ~ 20 working days

Packaging Details : Flight Case & Wooden Case

Product Name : SMD Stage LED Display

Tube Chip Color : Full Color

Display Function : Video

Brightness : 1500CD/sqm

Refresh Rate : 3840Hz

IP rate : 43

Material : Aluminum

Unit cabinet size : 500mm * 1000mm * 80mm

Contact Now

SMD Stage LED Display Structure Accurate Tolerance Fast Cabinet Splicing

SMD Stage LED Display

Adopting modular design, assembled cabinet can install and disassembly quickly and easily. It is easy to maintenance.
New structure design, can satisfy hoisting, overstow, indoor used requirements. Cabinet simplification.

Product features of SMD Stage LED Display

1. High quality LED chip and high anti-static electricity capacity.

2. Large viewing angle and smooth displaying provide excellent visual effect from every angle. High brightness led, the brightness is more than 2000cd/m2, and the wavelength range is ±1.5NM, same batch the LED brightness rate is 1:1.2, 130 wide viewing angle

Specification of SMD Stage LED Display:

Indoor slim rental P3.91mm LED screen (unit module size: 250mm * 250mm and unit cabinet size: 500mm * 1000mm) SMD Stage LED Display
LED Module	Pitch/mm	PH3.91
	Module size/mm	250*250
	Density of pixel/(dots/m2)	65746
	Pixel composition	1R1G1B
	Led encapsulation	SMD2121 3 IN 1
	Resolution of module	64*64
LED Screen	Optimum viewing distance	3~38M
	View angle	H:±160°;V±120°
	Average power consumption	300W/sqm
	Max power consumption	800W/sqm
	Module quantity	2* 4pcs
	Size of cabinet/mm	500*1000
	Resolution of cabinet	128*256
	Cabinet Material	die-casting aluminum cabinet
	Weight of cabinet	13Kg
	Driving method	1/16 scan constant current
	Frame frequency / Hz/S	≥60
	Refresh frequency/ Hz/S	1000~2000
	Brightness	1500cd/m2
	Operating temperature	–20C°～60C°
	Storage temperature	–40C°～70C°
	Operation humidity	10%-90%
	Storage humidity	10%-90%
	IP Rrating (Front/Rear)	IP43
	Working vlotage	AC220V / AC110V ±10%
	Grey scale/color depth	displaying colors≥16.7M(synchronized); 14bits
	Brightness adjustment	256 levels of each color(manually)
	Input signal	RF,S-Video,RGB,RGBH,YUV,YC&Composition ,etc
	Control system	linsn/Colorlight/Nova(sending card,receiving cards and Hubs)
	Average of non-failure life	≥50,00h
	Life span	≥100,000h
	Functionaless dot rate	≤0.0001
	Control distance	CAT cable: 100m; Muti-mode fiber: 500m; Single-mode fiber: 15km
